Product Details:
Payment & Shipping Terms:
|
| Brand Name: | MEANWELL | Certification: | CE UL CUL RoHS IP66 SELV |
|---|---|---|---|
| Output Power: | 60W | Output Type: | Single |
| Input Voltage: | 90 ~ 295VAC 127 ~ 417VDC | Output Voltage: | 12VDC |
| Output Current: | 5A | The Shell Material: | Metal |
| Warranty: | 3 Years | POWER FACTOR: | >0.9 |
| Model: | CEN-60 Series | ||
| High Light: | constant current power supply,meanwell switching power supply |
||
MEANWELL CEN-60 60W 12V Single Output LED Power Supply LED Driver
Features :
♦ Universal AC input / Full range (up to 295VAC)
♦ Protections: Short circuit / / Over voltage / Over temperature
♦ Output voltage and constant current level adjustable
♦ Built-in active PFC function
♦ IP66 design for indoor or outdoor installations
♦ Class 2 power unit
♦ Cooling by free air convection
♦ 100% full load burn-in test
♦ High reliability
♦ Suitable for LED lighting and moving sign applications
♦ Compliance to worldwide safety regulations for lighting
♦ Suitable for dry / damp / wet locations
♦ 3 years warranty
Specifications:
♦ 60w waterproof led driver
♦ Original Meanwell
♦ Prompt Delivery: 3~5 days
♦ Good Price High Quality
♦ 3 years warranty
| MODEL | CEN-60-12 | |||
| OUTPUT | DC VOLTAGE | 12V | ||
| CONSTANT CURRENT OPERATION VOLTAGE Note.5 | 9 ~ 12V | |||
| CURRENT RANGE | 0 ~ 5A | |||
| RATED CURRENT | 5A | |||
| RATED POWER | 60W | |||
| RIPPLE & NOISE (max.) Note.2 | 2Vp-p | |||
| VOLTAGE ADJ. RANGE | 10.8~13.5V | |||
| VOLTAGE ADJ. RANGE | 3.75 ~ 5A | |||
| VOLTAGE TOLERANCENote.3 | 10% | |||
| LINE REGULATION | 3.0% | |||
| LOAD REGULATION | 5.0% | |||
| SETUP, RISE TIME | 1400ms / 230VAC 2800ms / 115VAC at full load | |||
| INPUT | VOLTAGE RANGE | 90 ~ 295VAC 127 ~ 417VDC | ||
| FREQUENCY RANGE | 47 ~ 63Hz | |||
| POWER FACTOR | PF 0.9 at 75 ~ 100% load, 115VAC / 230VAC ; PF>0.97 / 115VAC PF>0.95 / 230VAC at full load | |||
| EFFICIENCY (Typ.) | 86% | |||
| AC CURRENT (Typ.) | 0.8A/115VAC 0.4A/230VAC | |||
| INRUSH CURRENT (Typ.) | 45A/230VAC | |||
| LEAKAGE CURRENT | <0.75mA / 240VAC | |||
| PROTECTION | OVER CURRENT | 95 ~ 110% | ||
| Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||
| SHORT CIRCUIT | Hiccup mode, recovers automatically after fault condition is removed | |||
| OVER VOLTAGE | 14.5~ 17V | |||
| Protection type : Shut down o/p voltage, re-power on to recover | ||||
| OVER TEMPERATURE | 85 10 (RTH1) | |||
| Protection type : Shut down o/p voltage, re-power on to recover | ||||
| ENVIRONMENT | WORKING TEMP. | -30 ~ +70°C (Refer to output load derating curve) | ||
| WORKING HUMIDITY | 20 ~ 95% RH non-condensing | |||
| STORAGE TEMP., HUMIDITY | -40 ~ +80 , 10 ~ 95% RH | |||
| TEMP. COEFFICIENT | 0.03%/ (0 ~ 50 ) | |||
| VIBRATION | 10 ~ 500Hz, 5G 12min./1cycle, period for? 72min. each along X, Y, Z axes | |||
| SAFETY &EMC(Note 4) | SAFETY STANDARDS | UL8750, TUV EN61347-1, EN61347-2-13, IP66 approved | ||
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC | |||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG: >100M Ohms / 500VDC / 25 / 70% RH | |||
| EMI CONDUCTION & RADIATION | Compliance to EN55015 | |||
| HARMONIC CURRENT | Compliance to EN61000-3-2 Class C ( 75% load) ; EN61000-3-3 | |||
| EMS IMMUNITY | Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, EN61547, light industry level (surge 4KV),? criteria A | |||
| OTHERS | MTBF | 523.4Khrs min. MIL-HDBK-217F (25 ) | ||
| DIMENSION | 183*62.5*40.5mm (L*W*H) | |||
| PACKING | 0.56Kg;24pcs/14.4Kg/1.11CUFT | |||
| NOTE | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. Direct connecting to LEDs is not suggested for models with RIPPLE & NOISE > 10% and using additional drivers is highly recommended. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Derating may be needed under low input voltage. Please check the static characteristics for more details. 5. Constant current operation region is within 65% ~100% rated output voltage. This is the suitable operation region for LED related applications, but please reconfirm special electrical requirements for some specific system design. 6. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. | |||
Our Services
1. Samples offer quicky.
2. Customized are welcomed.
3. No MOQ.
4. Good post-sale service and technical support
5. Shipping by DHL FEDEX UPS
FAQ
Q1. Can I have a sample order for LED driver?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for LED driver?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 3-7 years warranty to MeanWell dirver.
Q6: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new one.
