DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67

DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67
DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67 DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67 DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67 DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67

Large Image :  DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67

Product Details:
Place of Origin: Shenzhen China
Brand Name: Phensonlighting
Certification: CE ROHS
Model Number: PS-WL13Q36V24
Payment & Shipping Terms:
Minimum Order Quantity: 10m
Packaging Details: 5m in anti-static bag
Delivery Time: 15 days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 10000 Meter per Month
Detailed Product Description
Product Name: DMX512 RGB Wall Washer Light Color: Digital RGB
Working Voltage: 24VDC Produce Size: 18.5*9.5mm
IP Rating: IP67 Beam Angle: 15°/30°/45°/15*60°

DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67



Product description,
1. Adopting TPU material, it’s resistant to yellowing, high temperature, corrosion, weak acid and alkali, and has great flexibility.

2. PU glue is used for filling and sealing, so that it has strong adhesion, good durability and high reliability.

3. It can replace the traditional hard wall washer light or LED strip. It’s small in size, light in weight, flexible and easy to install.

4. Various beam angles (15°, 30°, 45°, 15*60°) are available for different applications.

5. With low voltage DC24V, higher safety factor.

6. It adopts high quality waterproof Light source with high brightness, low power consumption and good consistency.

7. There have Digital RGB version and Digital RGBW version for choice.

8. Can be used with various controllers to achieve Flash, Flow, Chase and other color changes.

9. Compatible with DMX512(1990) protocol and adopts RS485 signal trunk and signal differential transmission mode.



Electrical Data,

Model No PS-WL13Q36V24-RGB-MDX512
Input voltage 24VDC
Power 8.5W/m
Pixel/m 6
Beam angle 15°/30°/45°/15*60°
LEDs/m 36
Working hour 50000h
Working temperture -25℃-+45℃
Cuttable length(mm) 166.6
IP level IP67



Color R G B RGB
Power 4W 4W 4W 8.5W
Lumen 61 137 35 230
Wavelength 620-630nm 520-530nm 460-470nm



Color R G B W RGBW
Power 4W 4W 4W 3.2W 8.5
Lumen 72 211 46 163 492
Wavelength 620-630nm 520-530nm 460-470nm 3000K



Product Dimension,

DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67 0

Soft Wall Washer Application,

DMX512 RGB Outdoor Waterproof Soft Wall Washer Light IP67 1



Soft Wall Washer Correct Operation
1) During the installation process, the LED wall washer is taken out from the reel naturally and keep it as
straight as possible.

2) The LED wall washer should be kept vertical or horizontal during the installation process.

3) When LED wall washer meets the corner during the installation process, the LED wall washer must be kept facing up and the back facing down, maintaining a certain bending arc, Φ≥150mm.

4) Do not twist the LED wall washer during the installation process.

5) Do not fold the LED wall washer in half or bend it at a small angle during the installation.

6) When the LED wall washer meets the corner during the installation process, the LED wall washer must be
kept facing up and the back down, and it cannot be bent at right angles.
