Product Details:
Payment & Shipping Terms:
|
| Brand Name: | MEANWELL | Model Number: | CEN-75-24 |
|---|---|---|---|
| Output Power: | 75W | Output Type: | Single |
| Input Voltage: | 90 ~ 295VAC 127 ~ 417VDC | Output Voltage: | 24VDC |
| Output Current: | 3.125A | The Shell Material: | Metal |
| Warranty: | 3 Years | Certification: | CE UL CUL RoHS IP66 SELV |
| Efficiency: | Up To 91% | Working Tempera: | -30~70℃ |
| High Light: | meanwell led driver,meanwell switching power supply |
||
Meanwell Power Supply CEN-75 24VDC 75W Led Driver Module With PFC Function
Description
CEN series is high-grade led driver models, metal case, IP66 design for indoor or outdoor installations. OWA built-in active PFC function, with complete protections and safety certificates (UL, CB, CE, EMC, TUV). High efficiency up to 91%, long life and high reliability, 3 years warranty. This power supply combined with connectors provide a pleasing and imposing aesthetic with a unique and function design that combines modern aesthetics with the power of a high- grade product. Mean well high power AC/DC led driver range from 60 to 96 watts has been earning supreme customer's rating for a long time.
Features:
.Universal AC input (Up to 295VAC) /Full range
.Protections:Short circuit / Over current / Over voltage /Over temperature
.Built-in active PFC, PF>0.9 for 75% of load or higher
.IP66 design
.Meet 4kV surge immunity level (IEC61000-4-5)
.Class 2 power unit / Pass LPS
.Cooling by free air convection
.Suitable for dry, damp and wet location
.Suitable for LED lighting and moving sign applications
.3 years warranty
Specification:
| AC input voltage range | 90~295VAC ; 127~417VDC | |||
| AC inrush current (max.) | Cold start, 45A at 230VAC | |||
| DC adjustment range | ±10% rated output voltage | |||
| Current adjustment range | 75%~100% rated output current | |||
| Over current protection | 95%~110% constant current limiting, auto-recovery | |||
| Over voltage protection | 110%~140% shut off, re-power on to recover | |||
| Over temp. protection | 85oC ±10oC (RTH1) shut down o/p voltage, recovers automatically after fault condition goes down | |||
| Setup time | 1400ms at full load and 230VAC, no hold up time | |||
| Withstand voltage | I/P-O/P: 3.75kVAC, I/P-FG: 1.88kVAC, O/P-FG: 0.5kVAC | |||
| Working temperature | -30~+70OC (refer to output derating curve) | |||
| Safety standards | UL8750, UL879 (except for CEN-100), TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved |
|||
| EMC standards | EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 | |||
| Connection | Input | UL rated, SJTW 18AWGx3C (30cm) | ||
| Output | UL rated, SVT 18AWGx2C (30cm) | |||
| Dimension (LxWxH)(mm) | 185x 62.5x 40.5 | |||
Packaging & Delivery
Packaging Details
0.56Kg;24pcs/14.4Kg/1.11CUFT
Delivery Time
3 Days
Specifications
Meanwell Power Supply CEN-75 75W Led Driver Module
Protection:SC/OC/OV/OT
Built-in Active PFC Function
Class 2 Power/Pass LP
